hot water boiler/bath/heating/domestic hot water

Product details

1. The internal combustion wet-back flue gas three-return structure is adopted, and the structure is reasonable and compact.

2. The boiler adopts threaded smoke pipe to strengthen the heat transfer effect and greatly improve the thermal efficiency.

3. Front and rear detachable smoke box doors are convenient for boiler maintenance and repair.

4. The body can be galvanized as needed to provide clean domestic hot water.

5. Automatic operation By setting the start and stop temperature of the burner and the circulating water pump, the control system runs automatically according to the set conditions, and at the same time realizes the display of the system operating conditions and the temperature of the outlet and return water. Displays an alarm message when a fault occurs.

6. Manual operation In the manual state, the circulating water pump and the burner can be directly operated, and corresponding instructions are given when a fault occurs, and manual operation is refused to ensure the safety of the system. A condensing heat exchanger can be added to the flue gas outlet to reduce the exhaust gas temperature, absorb the sensible and latent heat in the flue gas, and improve the efficiency of the boiler (up to 95%).

Product parameters

Remark:
1. All the above values are based on the low calorific value of natural gas (LNG) 8,400kcal/Nm³, city gas (CG) low calorific value 4,000kcal/Nm³, coke oven gas low calorific value 4,200kcal/Nm³, diesel low calorific value 10,200kcal /kg, methanol low calorific value 4650kcal/kg is the standard calculation.
2. According to user needs, our company can provide other special types of boilers.
